TNMA series for Cast Iron:


                       CODE (Metric)            Shape           TBD2025   TBG2235   TBG2205   TBG3105   TBG3205



                        TNMA160404
                        TNMA160408                            ✓

                        TNMA160412                            ✓
                        TNMA160416

                        TNMA220404
                        TNMA220408
                        TNMA220416

                   TNMX series for heavy duty turning:


                    CODE (Metric)     Shape            Draft          L     ØI.C     S      Ød     r


                     TNMX1106-2                                      11.3   15.875   6.35   6.35   1.6

                     TNMX1509-2                                      15.9   22.225   9.52   7.94   1.6

                     TNMX15T916-2                                    15.9   22.225   9.72   7.94   1.6
