Internal Threading Partial Profile 55°
Pitch
JCM215 JCM415 JCP225 JCK15
Code (mm) r Y T
16NRAG55-M 48-8 0.07 1.7 3.65
06NRA55 06NLA55 48-16 0.07 1.9
08NRA55 08NLA55 48-16 0.07 0.9 2.38
11NRA55 11NLA55 48-8 0.07 0.9 3.18
16NRA55 16NLA55 18-8 0.07 0.9 3.65
16NRAG55 16NLAG55 7-5 0.07 1.7 3.65
16NRG55 16NLG55 4.5-4 0.25 1.7 3.65
22NRN55 22NLN55 4.5-4 0.4 2.5 4.9
27NRQ55 27ELQ55 4-2.5 0.68 6.4
27VNRV55 27VELV55 0.68 8.7
