Solid Metalworking LNC. Limited                                                             Milling


















                                                       Dimensions(mm)                     Grade


               Picture             Code
                                                  R     L     T    d1   ap   TBG5352C  TBG5302C  TBG5353E  TBG9502  TBG5355  TBG9108  TBG9508  TBG9105  TBG4351C



                               BLMP0603R-M        6     9    3.73  6.4   1   ●                 ★   ★   ●

                               BLMP0904R-MM       8    11.9   4.8  9.18  1.5  ●                ★   ★   ●











                                                                         ★Recommended Grade  ● Build-to-Order














                                                        Dimensions(mm)                     Grade

               Picture              Code
                                                   R     A    B     T     -   TBG5352C  TBG5302C  TBG5353E  TBG9502  TBG5355  TBG9108  TBG9508  TBG5302E  TBG4351C


                                 BNM160-M          8    16    12    4     -   ●   ●      ●   ●  ★   ★

                                 BNM200-M         10    20    15    5     -   ●   ●      ●   ●  ★   ★

                                 BNM250-M        12.5   25   18.5   6     -   ●   ●      ●   ●  ★   ★
                                 DHB160-F          8    16    12    3     -

                                 DHB200-F         10    20    15    3     -       ●      ●   ●  ●   ●  ★

                                 DHB250-F        12.5   25   18.5   4     -       ●      ●   ●  ●   ●  ★

                                                                        ★Recommended Grade ● Build-to-Order
