Solid Metalworking LNC. Limited                                                            Milling



















                                                           Dimensions(mm)                     Grade

                   Picture             Code
                                                      di    ap    S    F     r   TBG5352C  TBG5302C  TBG5353E  TBG9502  TBG5355  TBG9108  TBG9508  TBG9105  TBG4351C



                                 SNMU1305ANR-MT      13     6    6.5   3    0.8  ●                  ●  ★      ●

                                 SNMX1306ENTN-M      13.5   9.5  6.8   2.2  0.4  ●                  ●  ★      ●
                                 SNMX1306ANTN-M      13.5   9.5  7.0   2.2  0.4  ●                  ●  ★      ●

                                 SNMX1205ANN-GM      12.7   -    6.4   1.5   -   ●                  ●  ★      ●

                                  SNMX120512-FM      12.7   -    6.4    -   1.2  ●                  ●  ★      ●
                                                                               ★Recommended Grade ● Build-to-Order
















                                                           Dimensions(mm)                     Grade


                  Picture             Code
                                                     di    ap    S     F     r   TBG5352C  TBG5302C  TBG5353E  TBG9502  TBG5355  TBG9108  TBG9508  TBG9105  TBG4351C

                                                                            ★Recommended Grade ● Build-to-Order
                                  ONMU050505-MT      13    3.5   5.2   5    0.5  ●                 ●   ★      ●
